LED retrofits for recessed can lighting deliver energy efficiency with penetrating light in ceiling applications. Our retrofits are designed for use in 6-inch or larger recessed fixtures, enclosed fixtures, and are UL approved for damp environments.
7 models available



Recessed Can Retrofits
Replaces HID lamps in 6” recessed fixtures
Replaces 100-175W HID lamps
Up to 10,400 lumen output
Up to 93 lumens per watt efficacy
4000K, 4200K, 5000K or 5700K CCT
Pool and Spa models available



LED Lighting for:

Lobbies  |  Atriums  |  Entryways  |  Pools and spas

recessed can spec chart

MODEL NO. LED-8055E | 30W | Replaces up to 100W | E26 Edison Base

DESCRIPTION

30W LED Retrofit Lamp for replacing HID lamps up to 100W
120 – 277 Volt or 120-347V for Canadian “C” model, E26 base, Approved by UL for enclosed fixtures, Active cooling is provided by long life “Mag-Lev” cooling fan which keeps LED’s cool even when operating within enclosed light fixtures. UL1993 certified for USA and Canada.  Available in Daylight (5700K), Cool White (4200K), or Warm White (2700K).

SPECIFICATIONS

Bulb Type:                       Site / Recessed / Flood

Bulb Material:                Aluminum / Acrylic

Lumens:                          Up to 5700K

Dimensions:                   5.75″ X 4.7″

Input Voltage:               120-277VAC (USA) 120-347VAC (Canada)

CRI:                                  Up to 83.1

Lumens Per Watt:         62.9 / 73.9 / 72.9

Base Type:                      E26 Edison

Replaces:                        100W HID

Lifetime (hours):           Up to 50,000

Output Power:              30W

Beam Angle:                  120

Color:                              Warm White (2700K) / Cool White 4200K) / Daylight (5700K)

Dimmable:                     No

Warranty:                      5 year warranty

ul_us_can_Logo

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions

MODEL NO. LED-8055M | 30W | Replaces up to 30W | E39 Mogul Base

DESCRIPTION

30W LED Retrofit Lamp for replacing HID lamps up to 100W
120 – 277 Volt or 120-347V for Canadian “C” model, E26 base, Approved by UL for enclosed fixtures, Active cooling is provided by long life “Mag-Lev” cooling fan which keeps LED’s cool even when operating within enclosed light fixtures. UL1993 certified for USA and Canada.  Available in Daylight (5700K), Cool White (4200K), or Warm White (2700K).

SPECIFICATIONS

Bulb Type:                       Site / Recessed / Flood

Bulb Material:                Aluminum / Acrylic

Lumens:                          Up to 5700K

Dimensions:                   5.75″ X 4.7″

Input Voltage:                120-277VAC (USA) 120-347VAC (Canada)

CRI:                                   Up to  83.1

Lumens Per Watt:         62.9 / 73.9 / 72.9

Base Type:                      E39 Mogul

Replaces:                        100W HID

Lifetime (hours):           Up to 50,000

Output Power:              30W

Beam Angle:                  120

Color:                              Warm White (2700K) / Cool White 4200K) / Daylight (5700K)

Dimmable:                    No

Warranty:                      5 year warranty

ul_us_can_Logo

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions

MODEL NO. LED-8045M | 50W | Replaces up to 175W | E39 Mogul Base

DESCRIPTION

50W LED Retrofit Lamp for replacing HID lamps up to 175W
120 – 277 Volt or 120-347V for Canadian “C” model, E39 base, Approved by UL for enclosed fixtures, Active cooling is provided by long life “Mag-Lev” cooling fan which keeps LED’s cool even when operating within enclosed light fixtures. UL1993 certified and UL1598C classified for USA and Canada. Note: UL1598C keeps UL approval for fixture after ballast is removed or wired past. Available in Daylight (5000K), Cool White (4200K), or Warm White (2700K).

SPECIFICATIONS

Bulb Type:                     Site / Recessed / Flood

Bulb Material:              Aluminum / Acrylic

Lumens:                        Up to 5700K

Dimensions:                 7″ x 4.7”

Input Voltage:              120-277VAC (USA) 120-347VAC (Canada)

CRI:                                 Up to 81.9

Lumens Per Watt:        66.7 / 90.3 / 88.9

Base Type:                     E39 Mogul

Replaces:                       175W HID

Lifetime (hours):          Up to 50,000

Output Power:             50W

Beam Angle:                 45

Color:                            Warm White (2700K) / Cool White 4200K) / Daylight (5000K)

Dimmable:                   No

Warranty:                     5 year warranty

ul_us_can_Logo

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions

MODEL NO. LED-8055EC | 30W | Replaces up to 300W | E26 Edison Base | Color Changing

DESCRIPTION

Frosted Lens
Diffuses and spreads LED light

Advanced Active cooling
internal fan ensures long life

7 solid color modes

5 animated light shows

Replaces up to 300w

120 degree beam angle

for use in 6-inch or larger recessed fixtures

SPECIFICATIONS

Power Consumption         30w
Solid Colors                      7
Animated Modes              5
Lamp Diameter                4.7in
Lamp Length                   5.75in
Screw Base                     E26 Standard
Voltage                            120VAC

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions

MODEL NO. LED-8055EW | 30W | Replaces up to 300W | E26 Edison Base | White

DESCRIPTION

Replaces most PAR style pool lamps

Frosted Lens
Diffuses and spreads LED light

Advanced LED Cooling
Internal fan insures long LED life

Low maintenance – Long life LED
Up to 50,000 hours

SPECIFICATIONS

Power Consumption       30w
Input Voltage                    120V
Lamp Diameter               4.7in
Lamp Length                   5.75in
Screw Base                      E26 Standard

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions

MODEL NO. LED-8081E | 30W | Replaces up to 100W | E26 Edison Base

DESCRIPTION

Replaces up to 100w

120 degree beam angle

Dimmable 3 ways

0-40V DC dimming

PWM (Pulse Width Modulation)

Resistive

SPECIFICATIONS

Power Consumption       30w
Input Voltage                    120V
Lamp Diameter               4.7in
Lamp Length                   5.75in
Screw Base                      E26 Standard

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions

MODEL NO. LED-8082M | 45W | Replaces up to 175W | E39 Mogul Base

DESCRIPTION

Replaces up to 100w

120 degree beam angle

Dimmable 3 ways

0-40V DC dimming

PWM (Pulse Width Modulation)

Resistive

SPECIFICATIONS

Power Consumption       30w
Input Voltage                    120V
Lamp Diameter               4.7in
Lamp Length                   5.75in
Screw Base                      E26 Standard

PRODUCT NOTES
  • When installing LED-8000 series retrofit lamps within HID fixtures, ballast must be bypassed when present.
  • LED-8000 series retrofits are UL damp rated, sealing the existing HID fixture after installation will deliver best results.
  • Installing surge/lightning protectors is highly recommended and helps to eliminate premature driver failure caused by surges and other power fluctuations.
  • See Technical Documents web page for more detailed information and instructions
